| Projection Lens | One element, f-254mm |
| Condenser System | Fresnel Lens (Standard) |
| Projection Lamp |
240V-600W (Model RP-22) 24V-250W (Model RP-22A) 24V-250W/Twin (Model RP-22B) |
| Lamp Changer | By Lever Knob (Model RP-22B) |
| Power Source | AC 220-240V, 50Hz |
| Stage Aperture | 250mmx250mm Optional : 285mmx285mm |
| Reflector | Metal Reflector |
| Focussing | Metal, Rack & Pinion |
| Projection Distance | Effectively 1 to 3 Mtrs. |
| Cooling System | Fan Cooled |
| Safety Interlock | Opening of the top Cover by disconnecting power Lead. |
| Power Cable | Detachable Power Cable |
| Lamp Safety/Regulator | Variable Intensity Control knob. |
| Folding | Fixed Type (Detachable Parts) |
| Dimensions | 305x305x285mm |
| Accessories | Cellophane Roll Atachment, Writing Pack, Vinyl Cover etc. |
| Packing | Sturdy Cardboard Box Optional : Wooden Storing Cabinet |
| Optional Accessories | OHP Stand, Cellophane Roll, OHP Mount, Laser Pointer, Halogen Bulbs, Plywood Cabinet, Transparency Making Kit, OHP Trolley, Projection Screens, Film Slides & Strips Attachment |
