Category: Analog lab training modules

Objective : To study effect of Positive & Negative Clipping & Clamping on Sine Wave.
Features : Instrument comprises of DC Regulated Power Supply 0-3 VDC/150mA, Circuit diagram for Clipping & Clamping Printed, components placed inside & connections brought out at 4mm Sockets

No Description

Features : Instrument comprises of DC Regulated Power Supply 0-5VDC/150mA, two round meters (One milliammeter & One Galvanometer), Three set of Shunts resistance mounted behind the panel, connections of supplies, Meters & Shunts brought out at 4mm Sockets

Features : Instrument comprises of DC Regulated Power Supply 0-5VDC/150mA, two round meters (One Voltmeter & One Galvanometer), Three set of resistances mounted behind the panel, connections of supplies, Meters & Resistances brought out at 4mm Sockets

Features : Instrument comprises of DC Regulated power supply of 0-5V. Three round moving coil meters (one voltmeter, one milliammeter & one galvanometer). Three shunts, three Resistances are mounted on front panel.

Objective : To study VI Characteristics of Diac.
Features : Instrument comprises of DC Regulated Power Supply 0-50 VDC/150mA, two round meters for voltage & current measurement, one Diac mounted behind the panel, connections of Supplies & Diac brought out at 4mm Sockets
