Category: Analog lab training modules

Objective :To study V-I Characteristics of a LED.
Features :Instrument comprises of DC Regulated Power Supply 0-3 VDC/150mA, two round meters for voltage & current measurement, LED mounted on the panel, connections of Supplies & LED brought out at 4mm Sockets

Objective :To draw V-I Characteristics of Thyratron Valve & calculate its Ionization Potential.
Features :Instrument comprises of DC Regulated Power Supply 0- 15VDC/150mA & AC Power Supply 6.3 VAC/1Amp, two round meters for voltage & current measurement, valve diagram is Printed on Front panel, connections of supplies & valve brought out at 4 mm Sockets

Feature : Power supply of 9V, dB meter, Loudspeaker & microphone

Objective : To plot VDS versus I,D for different values of VGS.
Features : Instrument comprises of Two DC Regulated Power Supplies 0-5 VDC/150mA & 0-25VDC/150 mA, three round meters for voltage & current measurement, one MOSFET IRF 840 mounted behind the panel, connections of Supplies, Meters & MOSFET brought out at 4mm Sockets

Objective : To plot forward & reverse Characteristics of a Selenium Photo cell & to verify Inverse Square Law of Light.
Features : Selenium Photo cell mounted in metal box, light source. Photocell Kit with DC voltmeter of 1V & DC micrometer of 500μA, light source & required no. of patchcords
